There are three ways to set the power value：
1. In CW mode, rotate Rotary konb.
2.In CW mode, input value through number key boards directly，press Enter to confirm
3. In CW mode, move the stepping cursor by pressing
pressing .
To set power range, follow the steps:
Steps Operation
1
Press CW, then
Set the power range，press Enter to
2
confirm
3 Press Esc to escape.

5.1.4 Constant resistance operation

(Allowed setting range is 0.05Ω to 7500Ω)
There are three ways to set the resistance value：
1. In CR mode, rotate Rotary knob.
2.In CR mode, input value through number key boards directly，press Enter to confirm
3. In CR mode, move the stepping cursor by pressing
pressing .
To set resistance range, follow the steps:
Steps Operation
1
Press CR, then
Set the resistance range， press Enter to
2
confirm
3 Press Esc to escape.

5.2 Transient test operation

Transient operation enables the DC load to periodically switch between two levels.
To edit a transient test file, related parameters need to be set: A level, B level, time width
(only in pulse mode), frequency, duty and running mode (Continuous/Pulse/Toggled). If
in CC dynamic mode, user can set current rising and falling slope additionally.
Following is an example to illustrate the three transient operations.
(Shift)+CV.
(Shift) (Setup)
+CV .
43
IT8500 USER MANUAL
, and then adjust the power by
VFD display
RANGE=150.00W
RANGE =100.00W
HIGH=120.00V
, and then adjust the resistance by
VFD display
RANGE=7500.0Ω
RANGE =2000Ω
HIGH=120.0V
