P-LIM DELAY=3S
TIMER
LOAD-TIMER
ON
LOAD-TIMER=10.0S
OFF
V-RANGE
V-RANGE
ON
OFF
FILTER
MEASURE
FILTER COUNT = 2^14
TIME-V1
TIME-VOLT1=0.000V
TIME-V2
TIME-VOLT2=120.00V
CR-LED
CR-LED
ON
OFF
REM- SENSE
SENSE
ON
OFF
VON
LIVING
VON
VON POINT = 0.10V
LATCH
VON POINT = 0.10V
RESET
RESET NO
YES

4.6 Trigger function

4.6.1 Trigger operation

Triggering is used with the transient operation; list operation and test function.There are
four types of triggers you can use for IT8500+ products.
User Manual
Set the OPP delay time.
Set load on timer
Enable load-on timer
Set the load on time(0.1S~9999.9S)
Disable load on timer
Voltage auto-rangefuntion
Enable voltage auto range function
Disable voltage auto range function
Set the filter parameter
Filter count set, range 2~16
Set the start time, to measure the voltage
rise/fall time.
Set the end time, to measure the voltage
rise/fall time
Imitate LED (in CR mode)
Open the function(in CR mode,press shift+CV
to set Vd value)
Disenable the function
Remote sense function
Enable remote sense function
Disable remote sense function
Set the load's VON point
VON point living state
Set the VON value
VON point latch state, ON /OFF
Set the VON value
Reset the config menu
Do not reset
Reset
