(3)Time-out cut off
Step Operation
1
Press
range
2 Set discharge current,for example 2A
3 Set the stop voltage to 0V, then press Enter
to confirm.
4 Set the stop capability to maximum
999.999AH, press Enter to confirm.
5 Set the stop timer, for example, 3800S,
press Enter to confirm.
6 Save the battery test to specified file
7 Press Enter to confirm
(4) Any of the three conditions cut off
Step Operation
1
Press
2 Set discharge current,for example 2A
3 Set the stop voltage as needed,for
example,2V,then press Enter to confirm.
4 Set the stop capbility as needed,for
example,7AH,then press Enter to confirm.
5 Set the stop timer as needed,for
example,3800S,then press Enter to confirm.
6 Save the battery test to specified file
7 Press Enter to confirm
(5)go into battery test mode
Operation
1.Press (shift)+8(system) enter into
sysmtem menu
2.Press right key,select RUNMODE and
confirm with Enter button
3.Press direction
OCP_TEST,Press Enter to confirm.
4,Press Esc button to quit menu set
(6)Start battery test
Press (trigger) to provide a signal to start battery test.The discharing process will be
auto terminated when stop conditions are reached.
User Manual
(Shift)+5(Battery),set current
(Shift)+5(Battery),set current range
key to select
Display
0.0000V
RANGE = 0.00A
CURRENT = 2.000A
STOP VOLT=0V
STOP CAP=999.999AH
STOP TIMER=3800S
0.0000V
SAVE BATT FILE 1(1-10)
0.0000V
0.00W
Off cc
Display
0.0000V
RANGE = 0.00A
CURRENT = 2.000A
STOP VOLT=2V
STOP CAP=7AH
STOP TIMER=3800S
0.0000V
SAVE BATT FILE 1(1-10)
0.0000V
0.00W
Off cc
Display on front pannel
0.0000V 0.000A
POWER-ON BUZZER
0.0000V 0.000A
RUN <NORMAL
0.0000V 0.000A
RUN <BATTERY
0.0000V 0.000A
0S 0.000AH
38
IT8500 USER MANUAL
0.000A
0.000A
0.000A
I = 2.00A
0.000A
0.000A
0.000A
I = 2.00A
