Config Menu (Config) - ITech IT8500plus Series User Manual

HOLD
MEMORY
MEMORY
GROUP= 0
DISP-TIMER
DISPLAY
ON
OFF(default)
RS-232
4800_8N 1
9600_8N 1
RS-232
19200_8N 1
38400_8N 1
ADDRESS= 0
ADDRESS
RUN
NORMAL
BATTERY
RUNMODE
PROG_TEST
OCP_TEST
OPP_TEST
DEFAULT
DEFAULT
NO
YES

4.5 Config menu (Config)

Press (Shift)+9(Config) to enter the menus.
Max-P
MAX POWER=150.00W
A-LIMIT
A-LIMIT
ON
PROTECT
A-LIM POIN=30.000A
A-LIM DELAY=3S
OFF
P- LIMIT
P-LIM POIN=150.00W
Receving a command 9DH
Recall the prestored datas
0:indicates1-10 group；1:indicates 11-20group,
by parity of reasoning
Timer function
Enable timer function
Disable timer function
Baudrate 4800, data bit 8, none parity, stop bit 1
Baudrate 9600, data bit 8, none parity, stop bit 1
Baudrate 19200, data bit 8, none parity, stop bit
1
Baudrate 38400, data bit 8, none parity, stop bit
1
Set the instrument's address(0~31)
Runing mode at power on
Normal mode
Default in battery test mode at power on
Default in autotest mode at power on
Default in OCP test mode at power on
Default in OPP test mode at power on
Do not return instrument to factory default
settings.
Retrun instrument to factory default settings
Set hardware power protection
Set hardware OPP value
Set software current protecting
state
Enable software over current protection
function
Set the software OCP level
Set the OCP delay time
Disable the software OCP funtion
Set software power protecting
state.
Set the software OPP level.
