Installation Instructions - Command access PD25-UL-M Insert Instructions

Installation Instructions

1. Un-dog push pad with dogging key found in
box.
Loosen screws (2) and remove
3.
dogging bracket.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
When top push pad is removed, flip the
5.
device over and remove dogging screw.
2. Once loose, slide off back filler plate
exposing dogging .
Once removed, slide push pad assembly out
4.
the back of the device.
