Installation Instructions; M9900 Only - For M8800 Skip To Page 7 - Command access MLRK1-MRK Insert Instructions

M9900 O
-
F M8800
n ly
o r
1.
Remove head cover & Slide off housing, exposing the
baserail.
3.
Flip over push pad, exposing activating brackets.
5.
Holding activating bracket in place, grab motor kit & hook onto the pin on the outside of the activating bracket.
Next, rotate motor kit 180 degrees to the back of the push pad.
Back of push pad
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2

Installation Instructions

7
s k i p t o p a g e
activating bracket
Activating Bracket
Activating Bracket Pin
2.
Remove (2) Pins securing push pad to baserail.
4.
Pull activating bracket over onto spring and hold in place.
3
Pins
