Command access PD25-UL-M Insert Instructions

The PD25-UL-M-KIT is a field installable motorized latch pullback for Cal Royal 7700 & PD26 series.
A.
D.
1 - Motor Mount w/ MM4S series module
A.
1 - #50326 Link Pin
B
C.
2 - #40145 Retaining Ring
D.
1- 8' Lead with VD Connector
E.
1 - Push & go connector
1 - Dogging Hole Cap
F.
2 - #40333 Phillips Head Screw
G.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
Command Access is not a licensee, or affiliated, associated or connected with Allegion, Assa Abloy, Stanley, Schlage, Falcon, Von Duprin, Dorma, Sargent, Corbin Russwin, Yale, Emtek, Adams Rite, Best, Precision, Arrow,
Design Hardware, Cal Royal, Jackson, Kawneer, AHT, Marshall Best, Marks, Accurate, Baldwin, FSB, PDQ, Lawrence, Trans Atlantic, Hager, LSDA, General Lock, or Omnia or any of their subsidiaries or affiliates.
P D 2 5 - U L- M K I T
INSERT Instructions
E.
Ki t In cl u de s
F. G.
To o l s R e q ui r e d
• Cordless Drill
• Phillips head screwdriver
B.
C.
# 2 0 3 8 1 _ E
