APDSMW Manual.qxp_Layout 1 29/01/2016 13:01 Page 7
Lock Connection Example 2
types of release modes for alternative applications
dependent on the jumper link settings. LOCK1 options;
N.O
Volt-free
3
2
1
J1
J2
J3
N.C
Volt-free
Image of
3
2
1
jumper link
J1
J2
J3
N.O
12vDC300mA
MAX
3
2
1
J1
J2
J3
The door station has a secondary switch.
LOCK2 options;
N.O
Volt-free
3
2
1
J1
J2
J3
N.C
Volt-free
Image of
3
2
1
jumper link
J1
J2
J3
N.O
12vDC300mA
MAX
3
2
1
J1
J2
J3
Please refer to the operation guide for release instructions
7
