Lock Connection Example 1

6
Electro-magnetic lock
_
+
4
3
NC
+
_
+
_
System Wiring
Electronic lock
Lock -release time
N.C for Electro-magnetic lock
N.O for Electronic lock
At the rear of the door station
ensure that the jumper links cover pins
1 and 2, on both J3 and J2 positions
LOCK1
VCC
3 2
J1
BUS
J2
J3
1
Image of
jumper link
