Door Station Wiring Example 2

System PSU
Address ID
+V -V E L N
240vAC
System PSU
Seperator
Address ID Address ID
02 03
BUS BUS
Address ID
01 04
BUS BUS
Branch
Controller
Address ID 01
When using multiple door
stations ensure that each unit
has a seperate Address ID
Address ID Address ID
BUS
01 02
The dipswitches are accessible
on the rear of the door station
BUS
Address ID 02
Address ID Address ID
30 31
BUS BUS
Address ID Address ID
29
BUS BUS
Branch
Controller
Address ID Address ID
03 04
Cable run between
door station and
furthest monitor
should not exceed
150 meters
Each monitor requires the following:
1 Set up as a Master or Slave
2 Set up with a unique
Address ID: 01-32
32
Refer to the monitor's specific
Set up guide
Each branch controller requires the
following;
Adjusted dipswitch settings;
1
When in use with monitors
When in use with door stations
2 The branch controller at the end of
the line has the impedance switch
to ON the indication LED will
turn amber
Power supply
to be with-in
100 meters
or connection
of monitor
ON
1 2 3
ON
1 2 3
No cable
polarity
