Parts List – Multipress
Part Description
1 back ground link tube
2 left frame
3 right frame
4 back up link tube
5 front up link tube
6 reinforcing plate
7 reinforcing plate
8 hexagon bolt
9 washer
10 lock nut
11 hexagon bolt
12 washer
13 lock nut
16 barbell bar
17 guide rod
18 sliding sleeve
19 barbell bar stop
21 barbell bar plug
22 hexagon socket button
23 guide rod lock sleeve
24 headless hexagon
25 rubber cushion
26 safety hook left
27 safety hook right
28 back stand tube
29 back short ground
30 back short up link
31 back guide rod
32 big sliding sleeve
34 barbell plate holder
35 rubber cushion
36 hexagon bolt
37 hexagon bolt
38 spring washer
39 hexagon bolt
40 hexagon socket button
41 hexagon bolt
42 link frame
Type
140x59xt3.0
160x60xt4.0
M10x100
F10
M10
M12x75
F12
M12
F25x1850
F60xF48.5x27L
F51x42.5x36.6L
M12x40
M8x10
F60xF58xF26x25
F60xF27x42
M10x20
M12x30
F12.5xT3.0
M10x90
M10x20
M10x95
30
QTY
1
1
2
2
1
4
2
8
92
37
4
14
4
1
2
2
2
2
2
2
4
4
1
1
1
1
1
2
1
2
2
2
4
6
6
1
1
1
