Maxxus Multipress 9.1 Installation Manual page 21

Assembly - Multipress
78
Equipment
79
Attach the leg press frame (79) with the round head locking pin (80) and T
shape pin Ø10x100mm (81) to the short barbell shelf (78). Then put the holes
of the shelf (78) in the desired position on the front spar of right or left side
frame and fix them there with the T shape pin Ø10x75 (82).
82
81
80
Shelf for free barbell training, short version including height-adjustable
leg holder for Latzug (left tray)
Wide drawbar with chain
62
67
Wide drawbar with chain
62
ENG
63
78
79
77
82
81
80
21
