Scale [1:1]; Options - Barco Data 8200 Owner's Manual

Random Access Adjustment Mode

Scale [1:1]

Options

All manuals and user guides at all-guides.com
BLANKING
T O P
BOTTOM
LEFT
RIGHT
Select with or
then <ENTER>
<EXIT> to return.
Adjustment of the blanking on the top of the image
Adjustment of the blanking on the bottom of the image
Correct by pushing the control disc up or down
Adjustment of the blanking on the left side
Adjustment of the blanking on the right side
Correct by pushing the control disc to the right or to the left
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
[ ]
SCALE 1:x
OPTIONS
Select with or
then <ENTER>
<EXIT> to return.
GEOMETRY
SHIFT
SIZE
SIDE KEYSTONE
BLANKING
[ ]
SCALE 1:x
OPTIONS
GEOMETRY OPTIONS
Use the same side
keystone correction
for all files ?
[YES]
<ENTER> to toggle
<EXIT> to return
