Chapter 2. Functions
2.6.2

RTC (Real Time Clock) function

Since the RTC function is optio nal function, not all MASTER-K series support this function.
Please refer the Catalog and CPU manual for applicable models.
Clock operation by the RTC function is continued with a battery or super capacitor when the
CPU is powered off.
1) Clock data
Clock data is the data comprised of year, month, day, hour, minute, second, and date.
Data name
Year
Month
Date
Hour
Minute
Second
Day of the week
2) Precision
Max. 1.728 second per 24 hours (general temperature)
3) K10S / K30S / K60S
a) Read RTC data
RTC data is stored as f ollowing table.
Memory Area
(Word)
L012
L013
L014
L015
Example : 1998. 12. 22. 19:37:46, Tuesday
Description
The lower 2 digits or 4 digits of the Christian Era
1 to 12
1 to 31 (A leap year is distinguished automatically)
0 to 23 (24 hours)
0 to 59
0 to 59
0 Sunday
1 Monday
2 Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
Description
Higher byte Lower byte
Year -
Date Month
Day of the
Hour
week
Second Minute
2-24
Example data
(BCD format)
h98xx
h2212
h1902
h4637
