Chapter 4. Basic instructions
A flickering lamp (example of TON instruction)
1. Operation
By using two timers, a lamp flickers periodically while the P020 is on.
2. System diagram
Start
P020
3. Program
[Ladder program]
P020 T001
T000
[Time chart]
P020
Input module
P02
0
1
Program
2
3
.
.
.
.
.
F
[
TON
[
TON
T0 T1
4-29
Output module
P06
0
1
2
3
.
.
.
.
.
F
]
T000 00005 Set a Off time (0.5sec)
]
T001 00006 Set a On time (0.6 sec)
∴ T000, T001is set
( P065 )
[ ]
END
L
as 100 msec timer
