Appendix
A.2.2 K200S / K300S / K1000S
1) F relay
Contact Keyword
F0000
F0001
F0002
F0003
F0006
F0007
F0008 and
F0009
F000A
F000B to F000E
F000F p_STOP
F0010 p _ON
F0011 p_OFF
F0012 p_1ON
F0013 p_1OFF
F0014 p_STOG
F0015 to F001F
F0020
F0021
F0022
F0023
F0024
F0025 to F002F
F0030 s_HEAVY_ER
F0031 s_LIGHT_ER
F0032 s_WD_ER
F0033 s_IO_TYER
F0034 s_BAT_ER
F0035 s_FUSE_ER
F0036 to F0038
F0039 s_D_BCK_OK
F003A s_RTC_ER
F003B
F003C
F003D to F003F
Function
RUN mode Turns on when the CPU in the RUN mode.
Program mode Turns on when the CPU in the Program mode
Pause mode Turns on when the CPU in the Pause mode
Debug mode Turns on when the CPU in the Debug mode
Remote mode Turns on when the CPU in the Remote mode
User memory Turns on when a user memory is installed.
installation
Unused
User memory Turns on when a user memory is being
operation operated
Unused
Execution of the Turns on when the STOP instruction is being
STOP instruction operated.
Always On Always On
Always Off Always Off
1 Scan On 1 Scan On
1 Scan Off 1 Scan Off
Scan toggle Scan toggle
Unused
1 s tep run Turns on when the 1 step run is operated in
the Debug mode.
Breakpoint run Turns on when the breakpoint run is operated
in the Debug mode.
Scan run Turns on when the scan run is operated in the
Debug mode.
Coincident junction Turns on when the coincident junction run is
value run operated in the Debug mode.
Coincident word Turns on when the coincident word run is
value run operated in the Debug mode.
Unused
Fatal error Turns on when a fatal error has occurred.
Ordinary error Turns on when an ordinary error has occurred.
WDT Error Turns on when a watch dog timer error has
occurred.
I/O combination Turns on when an I/O error has occurred.
error (When one or more bit(s) of F0040 to F005F
turns on)
Battery voltage Turns on when the battery voltage has fallen
error below the defined value.
Fuse error Turns on when a fuse of output modules has
been disconnected.
Unused
Normal backup Turns on when the data backup is normal.
operation
RTC data error Turns on when the RTC data setting error has
occurred.
During program Turns on during program edit while running
edit the program.
Program edit error Turns on when a program edit error has
occurred while running the program.
Unused
A-6
