LSIS MASTER-K200S Instructions & Programming page 63

Chapter 3. Instructions
3.2.15 Flag instructions
Mnemonic Function
symbol No.
STC 002
CLC 003
CLE 009
3.2.16 Special module instructions
Mnemonic Function
symbol No.
GET 230
GETP 231
PUT 234
PUTP 235
3.2.17 Data link instructions
Mnemonic Function
symbol No.
READ 244
WRITE 245
RGET 232
RPUT 233
CONN 246
STATUS 247
Ladder symbol
STC
CLC
CLE
Ladder symbol
n1 S D n2
GET
GETP n1 S D n2
n1 S D n2
PUT
PUTP n1 S D n2
Ladder symbol
READ n1 st D S n SS
n1 st D S n SS
WRITE
n1 st D S n SS
RGET
n1 st D S n SS
RPUT
n1 st D SS
CONN
n1 st D SS
STATUS
3-18
Contents of processing
Set the carry flag
Clear the carry flag
Clear the error flag
Contents of processing
Read data from shared RAM of
a special module
Write data to shared RAM of
a special module
Contents of processing
Read /Write data of remote
station
Read / Write data of shared
RAM of remote special module
Establish a communication
channel
Read the information of remote
station
Page
○
5-102
★
5-103
Page
★
5-104
★
5-106
Page
5-108
★
5-111
5-113
★
5-116
★
★
5-118
