Chapter 4. Basic instructions
The fault of conveyer detecting circuit (example of TRTG instruction)
1. Operation
Detect the fault of conveyer by check that a product is passed within a specified period or not.
2. System diagram
Supplier
Conveyer
3. Program
P020
T005
Detecting
signal
Timer
contact
Operating
indicator
Detector
[
TRTG T005 00200
P020
T5
M100
4-37
If there is no product passing during 20
]
seconds, the timer turns off and M100 is
switched off.
( M100 )
During normal operation, the M100
keeps on state.
T=20sec
Input module
P02
0
1
2
.
.
.
.
.
.
F
