LSIS MASTER-K200S Instructions & Programming page 163

Chapter 5. Application instructions
- Execution conditions
Input condition
MULS, DMULS
MULSP, DMULSP
2) Program example
Program which stores the multiplication result of D0001 and D0002 at D0010, D0011 while P020 is
-
on.
P020
D0001
h04D2
(=1234)
Program which stores the multiplication result of D0001, D0002 and D0003,D0004 at D0010 ~
-
D0013 when P020 is switched on.
P020
D0001
hFDCD
(= –36840216)
Executed per scan
Executed only once
MULS D0001 D0002 D0010
D0002
× =
hE9D2
(= –5678)
DMULSP D0001 D0003 D0010
D0002 D0003
×
hDCE8 hCC78
D0013 D0012
=
h0071 h26FC
5-51
Executed per scan
Executed only once
D0011 D0010
hFF95 h1644
(= –7006652)
D0004
h4AAA
(= –864531798)
D0011 D0010
h794F hC210
