  • Page 1 / Perfect Charging / Perfect Welding / Solar Energy Operating Instructions FK 6000 Spare parts list FK 6000 Pipe Cooling unit FK 6000 - 400 V 42,0426,0018,EN 008-29032018...
  • Page 3 Thank you for the trust you have placed in our company and congratulations on buying this high-quality Fronius product. These instructions will help you familiarise yourself with the product. Reading the instructions carefully will enable you to learn about the many different features it has to offer.
  • Page 5: Table Of Contents

    Mains connection ..........................Mains voltage of FK 6000 ........................Setting the mains voltage of FK 6000 Pipe................... Setting the mains voltage of FK 6000 - 400 V ..................Start-up ..............................General remarks ........................... Guarantee provisions regarding the coolant pump ................
  • Page 6 Applicability of the “General Terms of Delivery and Payment” ............. Disposal ..............................Troubleshooting ............................Safety..............................Troubleshooting ............................ Technical data............................General remarks ........................... FK 6000 ..............................FK 6000 Pipe ............................FK 6000 - 400 V............................ Appendix Spare parts list: FK 6000 ...........................
  • Page 7: Safety Rules

    Safety rules General The device is manufactured using state-of-the-art technology and according to recognised safety standards. If used incorrectly or misused, however, it can cause: injury or death to the operator or a third party, damage to the device and other material assets belonging to the operat- ing company, inefficient operation of the device.
  • Page 8: Environmental Conditions

    Environmental Operation or storage of the device outside the stipulated area will be deemed conditions as not in accordance with the intended purpose. The manufacturer shall not be held liable for any damage arising from such usage. Ambient temperature range: during operation: -10 °C to + 40 °C (14 °F to 104 °F) during transport and storage: -20 °C to +55 °C (-4 °F to 131 °F) Relative humidity:...
  • Page 9: Protecting Yourself And Others

    Protecting your- Anyone working with the device exposes themselves to numerous risks, e.g. self and others flying sparks and hot pieces of metal Arc radiation, which can damage eyes and skin Hazardous electromagnetic fields, which can endanger the lives of those using cardiac pacemakers Risk of electrocution from mains current and welding current Greater noise pollution...
  • Page 10: Danger From Toxic Gases And Vapours

    Danger from toxic The fumes produced during welding contain harmful gases and vapours. gases and va- Welding fumes contain substances that may, under certain circumstances, pours cause birth defects or cancer. Keep your face away from welding fumes and gases. Fumes and hazardous gases must not be breathed in must be extracted from the working area using appropriate methods.
  • Page 11: Meandering Welding Currents

    During MIG/MAG welding and TIG welding, the welding wire, the wirespool, the feed rollers and all pieces of metal that are in contact with the welding wire are live. Always set the wirefeeder up on a sufficiently insulated surface or use a suit- able, insulated wirefeeder holder.
  • Page 12: Emc Device Classifications

    If the floor is electrically conductive, the device must be set up with sufficient insulating material to insulate it from the floor. If distribution boards, twin-head mounts, etc., are being used, note the follow- ing: The electrode of the welding torch / electrode holder that is not used is also live.
  • Page 13: Emf Measures

    EMF measures Electromagnetic fields may pose as yet unknown risks to health: effects on the health of others in the vicinity, e.g. wearers of pacemakers and hearing aids wearers of pacemakers must seek advice from their doctor before ap- proaching the device or any welding that is in progress for safety reasons, keep distances between the welding cables and the welder's head/torso as large as possible do not carry welding cables and hosepacks over the shoulders or wind...
  • Page 14: Factors Affecting Welding Results

    Use only suitable load-carrying equipment supplied by the manufacturer when transporting devices by crane. Hook chains and/or ropes onto all suspension points provided on the load-carrying equipment. Chains and ropes must be at the smallest angle possible to the vertical. Remove gas cylinder and wire-feed unit (MIG/MAG and TIG devices).
  • Page 15: Danger From Escaping Shielding Gas

    If the shielding gas cylinder is not connected, leave the valve cap in place on the cylinder. The manufacturer's instructions must be observed as well as applicable na- tional and international regulations for shielding gas cylinders and accesso- ries. Danger from es- Risk of suffocation from the uncontrolled escape of shielding gas caping shielding Shielding gas is colourless and odourless and, in the event of a leak, can dis-...
  • Page 16: Safety Measures In Normal Operation

    Safety measures Only operate the device when all safety devices are fully functional. If the safe- in normal opera- ty devices are not fully functional, there is a risk of tion injury or death to the operator or a third party damage to the device and other material assets belonging to the operator inefficient operation of the device Any safety devices that are not functioning properly must be repaired before...
  • Page 17: Safety Inspection

    (e.g. relevant product standards of the EN 60 974 series). Fronius International GmbH hereby declares that the device is compliant with Directive 2014/53/EU. The full text on the EU Declaration of Conformity can be found at the following address: http://www.fronius.com Devices marked with the CSA test mark satisfy the requirements of the rele- vant standards for Canada and the USA.
  • Page 18: Copyright

    Copyright Copyright of these operating instructions remains with the manufacturer. The text and illustrations are all technically correct at the time of printing. We reserve the right to make changes. The contents of the operating instructions shall not provide the basis for any claims whatsoever on the part of the pur- chaser.
  • Page 19: General

    Custom versions FK 6000 Pipe The FK 6000 Pipe cooling unit is a special version of the FK 6000 that is designed for de- ployment under extreme climatic conditions. The FK 6000 Pipe comes with the following additional equipment:...
  • Page 20 NOTE! Only fill or top up the reservoir of the FK 6000 Pipe cooling unit with orig- inal Fronius Pipe coolant. Due to their electrical conductivity and inadequate ma- terial compatibility, and to the high thermal stresses encountered in this application, all other antifreeze agents are unsuitable for use here.
  • Page 21: Control Elements And Connections

    Control elements and connections Safety WARNING! Operating the equipment incorrectly can cause serious injury and damage. Do not use the functions described until you have thoroughly read and understood the following documents: these operating instructions all the operating instructions for the system components, especially the safe- ty rules Front Coolant inspection window...
  • Page 22: Possible Configurations

    Possible configurations Safety WARNING! An electric shock can be fatal. If the unit is plugged into the mains electricity supply during installation, there is a high risk of very serious injury and damage. Only carry out any work on the unit if the mains switch is in the “O”...
  • Page 23: Connecting In Series Using Interconnecting Hosepack

    Connecting in se- This configuration should be used for: ries using inter- TimeTwin Digital applications where the wirefeeders are placed near the power sourc- connecting hosepack Alternatively, a series connection is also possible using connection hoses Connecting in series using interconnecting hosepack Double quick-acting coupler...
  • Page 24: Connecting In Series Using Connection Hoses

    Connecting in se- This configuration should be used for: ries using con- TimeTwin Digital applications where the wirefeeders are placed near the power sourc- nection hoses Alternatively, a series connection is also possible using connection hoses Connecting in series using connection hoses Connecting lead...
  • Page 25: Before Commissioning

    Before commissioning Safety WARNING! Operating the equipment incorrectly can cause serious injury and damage. Do not use the functions described until you have thoroughly read and understood the following documents: these operating instructions all the operating instructions for the system components, especially the safe- ty rules Utilisation for in- The cooling unit may ONLY be used for cooling welding system components used in MIG/...
  • Page 26: Mains Connection

    FK 6000: fixed mains voltage Setting the mains The FK 6000 Pipe cooling unit can be used with different mains voltages. The mains volt- voltage of FK age set at the factory is shown on the rating plate.
  • Page 27: Setting The Mains Voltage Of Fk 6000 - 400 V

    Check that all cables are fixed firmly Close the housing Cross out the mains voltage originally entered on the rating plate and - in the empty box - enter the mains voltage that you have just set. FK 6000 - 400 V: Setting the mains voltage...
  • Page 28: Start-Up

    The manufacturer accepts no liability for damage caused in such cases. Information on Only use original Fronius coolant for the filling of the cooling unit. Other antifreezers cannot the coolant be recommended due to their electric conductivity and compatibility.
  • Page 29: Changing The Welding Torch

    Switch mains switch of the power source(s) in position “I” - the cooling pump starts op- eration. Check coolant flow until proper flow is ensured. If necessary, deairate coolant circula- tion. NOTE! During welding check coolant flow at regular intervals - a proper return flow must be visible in the filler neck.
  • Page 30: Care, Maintenance And Disposal

    Care, maintenance and disposal General remarks Under normal operating conditions the cooling unit requires only a minimum of care and maintenance. However, it is indispensable to follow some important points to ensure the operationality of the welding machine for many years. Safety WARNING! An electric shock can be fatal.
  • Page 31: Every Week

    Payment” max. 8 operating hours per day (single-shift operation) only Fronius coolant may be used the unit is given regular maintenance and the coolant is changed regularly Disposal Dispose of in accordance with the applicable national and local regulations.
  • Page 32: Troubleshooting

    Troubleshooting Safety WARNING! An electric shock can be fatal. Before opening up the unit: Shift the mains switch into the “O” position Unplug the unit from the mains Put up an easy-to-understand warning sign to stop anybody inadvertently switching it back on again Using a suitable measuring instrument, check to make sure that electrically charged components (e.g.
  • Page 33 High operating noise level Cause: Coolant level too low Remedy: Refill coolant Cause: Cooling pump defective Remedy: Replace coolant pump...
  • Page 34: Technical Data

    Q (l/min) The flow-rate Q will depend upon: the number of interconnecting hosepacks or connection hoses, and their lengths the diameter of the hose FK 6000 Storage temperature -25 °C to +55 °C -13 °F to +131 °F Operating temperature -10 °C to +40 °C...
  • Page 35: Fk 6000 Pipe

    FK 6000 Pipe Storage temperature -50 °C to +55 °C -58 °F to +131 °F Operating temperature -25 °C to +40 °C -13 °F to +104 °F Mains voltage (auto-transformer) 110* / 230 V Mains voltage tolerance +/- 10 %...
  • Page 36 FK 6000 - 400 V Storage temperature -25 °C to +55 °C -13 °F to +131 °F Operating temperature -10 °C to +40 °C +14 °F to +104 °F Mains voltage (auto-transformer) 110 / 230 / 400* / 440 / 460 V...
  • Page 37: Appendix

    Appendix...
  • Page 38: Spare Parts List: Fk 6000

    Spare parts list: FK 6000...
  • Page 40 FRONIUS INTERNATIONAL GMBH Froniusplatz 1, A-4600 Wels, Austria Tel: +43 (0)7242 241-0, Fax: +43 (0)7242 241-3940 E-Mail: sales@fronius.com www.fronius.com www.fronius.com/addresses Under http://www.fronius.com/addresses you will find all addresses of our Sales & service partners and Locations...
