7.
Re-attach head assembly by securing (2) screws.
CVR
STEP 2
Installing Kit
-
9.
Add bracket #50453 to front activating bracket. Dropping it over the top and securing it with the
screw provided.
10.
On the baserail, remove the back (2)
screws from the dogging bracket.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
RIM
BEFORE MOVING TO STEP 2 - SEE STEP C on PAGE
PILOT HOLE IN INCHES (")
8.
Next, we'll be installing the kit in between the
activating brackets on the exposed baserail.
**Important
BEFORE
PILOT HOLE
AMOUNT REMOVED IN INCHES (")
1/2"
1/4"
11.
Make sure scissor bracket on bottom side is diagonal
& screws are flush before installing.
Info**
AFTER
5/8"
5/16"
8
