sync signal is present, the input 1 LED indicator still lights
to indicate that the unit is still powered on.

Front Panel Features and Operation

1
1
2
2
1 Input 1 LED indicator — This LED lights green whenever
Input 1 (video and audio) is selected.
Input 2 LED indicator — This LED lights green whenever
2
Input 2 (video and audio) is selected.
Input select toggle switch — Toggling this switch up selects
3
Input 1; toggling it down selects Input 2.
4 Input 1 video — Input VGA-UXGA, RGBHV, RGBS, RGsB,
RsGsBs, component video, or HDTV component video through
this 15-pin female VGA connector.
5 Input 1 audio — Input unbalanced
stereo audio through this 3.5 mm mini
audio jack. See the diagram at right.
Input 2 video — Input VGA-
6
UXGA, RGBHV, RGBS, RGsB,
RsGsBs, component video, or HDTV
component video through this 15-pin female VGA connector.
7 Input 2 audio — Input unbalanced stereo audio through this
3.5 mm mini audio jack. See the previous wiring diagram (
www.camboard.de
CAMBOARD Electronics
When autoswitch mode is active, both daisy chaining
and the front panel's input toggle switch are disabled,
and the input cannot be manually switched. Any
attempt to toggle the switch while the switcher is in
this mode results in the flashing of the currently active
input's LED indicator. Contact closure is also disabled
while in autoswitch mode.
INPUT 1
3
4
The LEDs
1
indicators. When the switcher is powered up, the
selected input's LED lights green.
Tel. 07131 911201 ce-info@camboard.de
VSW 2VGA A • Installation and Operation
Fax 07131 911203
INPUT 2
VSW 2VGA A
5 6
and above also serve as power up
2
3.5 mm Stereo Plug Connector
7
Tip (L)
Ring (R)
Sleeve ( )
(unbalanced)
).
5
2-13
