OPEN
All jumpers are set open (disabled) by default.
The jumpers must be set closed (enabled) when
the switchers are daisy chained together.
Open or close the indicated jumpers in the table below,
as needed, to adjust the appropriate settings.
Input 1
Input 2
Output
4 After setting the appropriate jumpers, replace the
switcher's cover using the screws previously removed.
Connect and power up all of the switcher's attached
devices, then power up the VSW 2VGA A.

Power considerations

One power supply can power up to five daisy chained
switchers. Additional switchers require one or more power
supplies.
www.camboard.de Tel. 07131 911201
Fax 07131 911203
Pin 5 − Control Pin 9 − +5 VDC
JMP 1
JMP 3
JMP 5
When the switchers are not daisy chained together, set all
jumpers back to the default (open) position.
The maximum number of switchers that can be daisy
chained is limited by several factors: power consumption,
cable lengths, and the overall distortion of the video and
audio signals.
ce-info@camboard.de
VSW 2VGA A • Installation and Operation
CLOSED
JMP 2
JMP 4
JMP 6
2-19
