4.
COMPONENT IDENTIFICATION
■ FRONT VIEW
(3) CF Card Slot
(4) Eject Button
(1) Touch Panel Screen
Trend chart and other data views and setup views are displayed.
(2) Front Cover
Access to the CF Card Slot.
(3) CF Card Slot
Insert a CF Card.
(4) Eject Button
Used to retrieve the CF Card.
(5) Reset Button
Used to restart the 73VR1100.
(6) CF Card Access Indicator LED
Red light turns on during the CF Card is accessed.
(7) USB Connector
Connect an USB flash-memory.
(5) Reset Button
– 7 –
(1) Touch Panel Screen
(2) Front Cover
(7) USB Connector
(6) CF Card Access Indicator LED
