6.

INSTALLING THE UNIT

Mount the 73VR1100 on the surface of a panel.
■ ADAPTABLE PANEL
Panel thickness: 2 to 26 mm
Material: Steel
■ PANEL CUTOUT Unit: mm
■ SINGLE MOUNTING
Number
2
3
4
5
6
7
8
9
10
n
Notes
1. Dimensional tolerance ±3% unless otherwise specified.
(±0.3 mm for <10 mm)
2. Desktop type cannot be mounted on a panel surface.
+2
137
0
+2
L
(mm)
0
282
426
570
714
858
1002
1146
1290
1434
(114
n) – 6
×
■ VERTICAL CLUSTERED MOUNTING
(max. 3 units)
■ HORIZONTAL CLUSTERED MOUNTING
– 11 –
+2
137
0
175 min
+2
L
0
