COMPONENT IDENTIFICATION

Station Address Setting
Rotary SW
Status Indicator LED
■ STATUS INDICATOR LED
ID
COLOR
STATUS
PWR
Red
ON
Blinking
approx. 0.5 Hz
Blinking
approx. 2 Hz
OFF
RUN
Red
ON
ERR
Red
ON
SD
Red
ON
RD
Red
ON
■ STATION ADDRESS
Station Address is selected between 1 and 64 in decimal.
The left switch determines the tenth place digit, while the
right switch does the ones place digit of the address.
(Factory setting: 00)
■ BAUD RATE
Baud Rate is selected with the rotary switch.
(Factory setting: 0: 156 kbps)
0 : 156 kbps
1 : 625 kbps
2 : 2.5 Mbps
3 : 5 Mbps
4 : 10 Mbps
Baud Rate Setting Rotary SW
X10
X1
PWR
ERR
RD
RUN
SD
STATION ADD.
4
5
6
7
1
2
3
CC-Link, Power Supply
Terminals
FUNCTION
Normal
Input overload or no input
Setting error or device
error
Error in the internal 5V
Refresh data received
normally
Received data error
Data transmitting
Data receiving
Station Address Setting (x1)
Station Address Setting (x10)
Baud Rate Setting
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
Operating Mode Setting DIP SW (SW1)
PC Configurator Jack
1 2 3 4 5 6 7 8
CNFG.
B.RATE
10 11 12 13
14
15 16 17 18
1
2
3
4
5
6
7
Voltage, Current, Discrete Input Terminals
■ OPERATING MODE SETTING
(*) Factory setting
• System Configuration (SW1-1, 1-2)
SW1-1
SW1-2
OFF
OFF
ON
OFF
OFF
ON
ON
ON
• Balanced or Unbalanced Load (SW1-3)
SW1-3
OFF
ON
• Clamp Sensor Type (SW1-4, 1-5, 1-6)
Clamp sensor type setting is common to all circuits.
The sensor type and other settings for individual circuit is
available with the PC Configurator.
SW1-4
SW1-5
SW1-6
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
ON
OFF
OFF
ON
• Configuration Mode (SW1-8)
SW1-8

CONFIGURATION MODE

OFF
DIP switch setting (*)
(PC Configurator setting is invalid.)
ON
PC Configurator and communication
(DIP switch setting is invalid.)
Note 1: Turn on the power supply to the unit after setting sta-
tion address, baud rate and operating mode.
Note 2: Be sure to set unused SW1-7 to OFF.
R7CWTU
8
9
SYSTEM CONFIGURATION
Three-phase / 3-wire (*)
Single-phase / 2-wire
Single-phase / 3-wire
Three-phase / 4-wire
BALANCED / UNBALANCED
Unbalanced (*)
Balanced
CLAMP SENSOR TYPE
CLSE-R5 (5A) (*)
CLSE-05 (50A)
CLSE-10 (100A)
ON
CLSE-20 (200A)
CLSE-40 (400A)
ON
CLSE-60 (600A)
EM-7814 Rev.3 P. 2 / 18
