FC 300 Operating Instructions
8-** Comm. and options
Par. Parameter description
No. #
8-0* General settings
8-01 Control site
8-02 Controlword source
8-03 Controlword Timeout Time
8-04 Controlword Timeout Function
8-05 End-of-timeout function
8-06 Reset Controlword Timeout
8-07 Diagnosis trigger
8-1* Ctrl. word settings
8-10 Control word profile
8-3* FC Port settings
8-30 Protocol
8-31 Address
8-32 FC port baudrate
8-35 Minimum response delay
8-36 Max response delay
8-37 Max inter-char delay
8-5* Digital/Bus
8-50 Coasting select
8-51 Quick stop select
8-52 DC Brake select
8-53 Start select
8-54 Reversing select
8-55 Set-up select
8-56 Preset reference select
8-9* Bus jog
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
*
default setting ( ) display text
42
How to Programme
Default value
[0] Digital and ctrl.word
[0] FC RS485
1.0 s
[0] Off
[1] Resume set-up
[0] Do not reset
[0] Disable
[0] FC profile
[0] FC
1
[2] 9600 Baud
10 ms
5000 ms
25 ms
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
[3] Logic OR
100 RPM
200 RPM
[ ] value for use in communication via serial communication port
MG.33.A2.02 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
All set-ups TRUE
1 set-up FALSE
All set-ups TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint8
- Uint8
-3 Uint16
-3 Uint16
-3 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
67 Uint16
67 Uint16
