FC 300 Operating Instructions
0-** Operation/Display
Par. Parameter description
No. #
0-0* Basic settings
0-01 Language
0-04 Operating state at Power-up (Hand)
0-1* Set-up handling
0-10 Active set-up
0-11 Edit set-up
0-12 This set-up linked to
0-13 Readout: Linked set-ups
0-14 Readout: Edit set-ups / channel
0-2* LCP Display
0-20 Display line 1.1 small
0-21 Display line 1.2 small
0-22 Display line 1.3 small
0-23 Display line 2 large
0-24 Display line 3 large
0-25 My personal menu
0-4* LCP keypad
0-40 [Hand on] key on LCP
0-41 [Off] key on LCP
0-42 [Auto on] key on LCP
0-43 [Reset] key on LCP
0-5* Copy/Save
0-50 LCP copy
0-51 Set-up copy
0-6* Password
0-60 Main menu password
0-61 Access to main menu w/o password
0-65 Quick menu password
0-66 Access to quick menu w/o password
*
default setting ( ) display text
How to Programme
Default value
[0] English
[1] Forced stop, ref=old
[1] Setup 1
[1] Setup 1
[1] Setup 1
0
0
[1617] Speed (RPM)
[1614] Motor current
[1610] Power (kW)
[1613] Frequency
[1602] Reference %
User depedent
[1] Enabled
[1] Enabled
[1] Enabled
[1] Enabled
[0] No copy
[0] No copy
100
[0] Full access
200
[0] Full access
[ ] value for use in communication via serial communication port
MG.33.A2.02 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
1 set-up TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
0 Uint32
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
0 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
0 Uint16
- Uint8
35
