INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–

4 COMPONENT PARTS LOCATION

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1. Rear Beacon Plug B (H1) 2. CCL1 Device (U1)
4. Plug B – Meter (AN2)
7. RFID Reader (B3)
10. Heater (R1)
13. Power Supply (G1)
16. Tamper switch (S1)
19. Relay power supply (K3) 20. Plug A – MCB (Q1)
22. Type 2 socket (B1)
25. CBS-4C RCD (AF1)
28. Beacon led driver
(X1.1)
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941
Web: www.circontrol.com – E-mail:
5. Plug A – Mode 3 (AM3-1)
8. LCD Display (H3)
11. MCB Power Supply (Q3)
14. AC Power terminals
17. Plug A – Contactor (K1)
–
23. Plug A
electromagnet (K7)
26. Beacon led driver (X2.1)
ps-suport@circontrol.com
3. Plug A – Meter (AN1)
6. Plug B – Mode 3 (AM3-2)
9. Type 2 socket (B2)
12. WGS-20 (T3)
15. Thermostat (G3)
18. Plug B – Contactor (K2)
21. Plug B – MCB (Q2)
Relay 24. Plug B
electromagnet Plug B (K8)
27. Rear beacon Plug A (H2)
28
27
26
25
24
23
22
21
20
19
18
17
16
–
Relay
5
