INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–
The unit is ready to electrical connections described in section nº 8.
It is recommended to keep a distance of approximately 40cm of electric wires
before cutting.
4
5
Proceed with input connections, please see section 8.
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941
Web: www.circontrol.com – E-mail:
ps-suport@circontrol.com
40cm
18
