INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–

10 CLOSING THE UNIT

STEP
For the closure of the rear cover the following M8x20 Allen screws & rings are
supplied. The two upper screws, with a standard flat ring must be used for the
two holes at top of the cover; the six screws equipped with a special sealing
ring, must be placed for the holes at the sides.
1
In order to keep the optimal sealing,
must be done alternating from left to
right and from up to down screws.
