INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–
6.4
ASSEMBLY MAIN BODY
STEP
After unpack main body, remove 8 screws from rear cover.
1
Assembly main body with two covers plates and the four M8 supplied screws
as shown below.
2
ATTENTION:
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941
Web: www.circontrol.com – E-mail:
ACTION
Do not trap connection wires with main body.
