INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–
6.3
FOUNDATION PROCEDURE
STEP
ACTION
The four "L" threaded bars must be placed and cemented underground in
the foundation place as shows bellow figure.
1
Drawing foundation dimensions are minimum recommended to fix post
to the ground, please consider hardness ground conditions.
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941
9
Web: www.circontrol.com – E-mail:
ps-suport@circontrol.com
