INSTALLATION MANUAL –CCL-PT3 SMART & CCL-PT3 SMART 3G–
Connections wires must be introduced and fixed as shown in the back view
image.
5
Wire Input
Adjust the lower four nuts, you can properly level the main structure.
6
CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona)
Tel.: +34 937 362 940 – Fax: +34 937 362 941
Web: www.circontrol.com – E-mail:
BACK VIEW
ps-suport@circontrol.com
11
