Martin Maxxyz User Manual page 144

M T
A C R O Y P E S
The Maxxyz console currently supports 10 different Macro types.
Macro Type
Trigger
Release
Pause
Select
Select Main
Go to Bank
Script Execute
Rel All
Rel All CL
Rel All OR
Set CL Value
MIDImacro
C M
R E A T I N G A
To use a macro in a cuelist, follow this procedure:
1 Select the desired cuelist and view it in the Cuelist window.
2 Highlight the cue that you wish to have trigger the macro. Note that the macro will execute as
soon as the cue starts.
3 Select "Add Macro" at the top to the cuelist. The macro will be added directly below the selected
cue.
2.This will prevent the console from attempting to simultaneously execute several different Macros which can
have a negative impact on console speed performance.
144
Action
Same as pressing Go button on specified cuelist
Will release the specified cuelist
Will pause any cue running in the specified cuelist
Selects the specified cuelist
Changes the cuelist assigned to the Main Go area.
Loads the specified bank onto the playback faders. When selected,
the option of changing the bank on the main console (default) or an
attached Maxxyz Playback Wing module is presented in a pull down
window. Playback Wing modules are identified as "Wing ID 0"
through "Wing ID 36." Wing ID's are determined by setting a DIP
switch found on the wing module. For details on setting these IDs,
please refer to your Maxxyz Playback Wing Manual.
This option is for application specific instances only. Please contact
Technical Support for more information.
This will release all standard, chase, timecode, and override cuelists.
You can also specify a single cuelist that is not to be released.
This will release all standard, chase, and timecode cuelists, but not
overrides. You can also specify a single cuelist that is not to be
released.
.This will release all override cuelists, but not chases, timecode, or
standard cuelists. You can also specify a single cuelist that is not to
be released.
This macro will allow you to proportionately adjust the intensity
values of a specified cuelist. For more information, please see
"Mastering the Level of a Cuelist Using a Macro" on page 146.
A MIDImacro allows you to use MIDI to trigger cuelists and
accomplish other functions. For more information, refer to
"MIDImacro" on page 146.
A C R O
Maxxyz
