Ergotron StyleView LiFe Power Upgrade System Installation Manual page 8

SV40/SV41
b
Route SOCI cable down through bottom of enclosure and plug into power module.
10
Route power strip from inside enclosure down to power module.
Power strip should be used to plug your equipment into.
8 of 17
c
Replace power module cover.
WARNING! Connecting electrical equipment
to the outlet effectively leads to creating
a medical system and the result can be a
reduced level of safety.
Leave enough slack in
cable to allow full range
of motion.
Leave enough slack in
cable to allow full range
of motion.
888-83-072-G-01 rev. D • 01/15
