Safety
WARNING! Connecting electrical equipment to the outlet effectively leads to creating a medical
system and the result can be a reduced level of safety.
PRESS
0%
CHG ALERT
100%
SOCI (State of Charge Indicator): Display:
• 1 amber LED and 4 Green LEDs represent that battery is fully charged, 100%.
• 1 flashing amber LED indicates that less than 10% of the battery's capacity remains. The battery is then ready
to be replaced with a charged battery or charged by plugging the power cord into an AC wall outlet.
0%
888-83-072-G-01 rev. D• 01/15
CAUTION!
Do not let battery
bump into anything.
Failure to follow
these instructions
may cause
equipment damage.
Battery Display:
• Press the "PRESS" button on the battery to display the percentage of usable energy
remaining.
100%
• 1 amber LED and 4 Green LEDs represent that battery is fully charged, 100%.
• 1 flashing amber LED indicates that less than 10% of the battery's capacity remains.
The battery is then ready to be replaced with a charged battery or charged by
plugging the power cord into an AC wall outlet.
CAUTION!
Do not move cart while battery
is unlatched to harness. Make
sure battery is fully secure
in the bottom of the harness
as well as attached securely
at the top. Failure to follow
these instructions may cause
equipment damage.
