Ergotron StyleView LiFe Power Upgrade System Installation Manual page 13

CARTS WITH DUAL T-SLOTS ON REAR OF CART:
8
Attach power strip.
Power strip should be used to plug your equipment into.
9
Attach coiled cord.
Plug coiled cord into wall outlet to charge battery.
10
BATTERY ATTACHMENT/REMOVAL
888-83-072-G-01 rev. D• 01/15
WARNING! Connecting electrical equipment to the outlet effectively
leads to creating a medical system and the result can be a reduced
level of safety.
END OF INSTALLATION
Leave enough slack in
cable to allow full range
of motion.
Battery Removal
13 of 17
