Figure 3-17: Stream view - PCR graph - PCR overall jitter

The Maximum PCR Accuracy Error can be adjusted for all PIDs as follows:
Tests screen PCR Tests section
parameter (right-click)
For individual PIDs:
PIDs screen Test: select PCR Jitter
click) Max PCR overall jitter.
Right-click on the graph and set the limit for each PID.
MTM400 MPEG Transport Stream Monitor User Manual
PCR Overall Jitter (PCR_OJ)
Max PCR overall jitter.
individual PID parameter (right-
