Rectifying faults

Machine faults (error messages)

7.2 Machine faults (error messages)
A welding machine error is indicated by the collective fault signal lamp (A1) lighting up and an
error code (see table) being displayed in the machine control display. In the event of a machine
error, the power unit shuts down.
The display of possible error numbers depends on the machine version (interfaces/functions).
•
If multiple errors occur, these are displayed in succession.
•
Document machine errors and inform service staff as necessary.
Error message
E 0
E 4
E 5
E 6
E 7
E 9
E12
E13
E14
E15
E23
E32
E33
E34
E37
E40
E55
E58
7.3

Display machine control software version

The query of the software versions only serves to inform the authorised service staff. It is available in the
machine configuration menu > see 5.9 chapter.
38
Possible cause
Start signal set in the event of
errors
Temperature error
Mains overvoltage
Mains undervoltage
Electronics error
Secondary overvoltage
Voltage reduction error (VRD)
Electronics error
Adjustment error in current
recording
Error in on of the electronics
supply voltages
Temperature error
Electronics error
Adjustment error in voltage
recording
Electronics error
Temperature error
Motor fault
Failure of a mains phase
Short circuit in welding circuit
Remedy
Do not press the torch trigger or the foot-
operated remote control
Allow the machine to cool down
Switch off the machine and check the mains
voltage
Switch the machine on and off again.
If the error persists, notify service department
Switch off the machine, place the electrode
holder in an insulated position and switch the
machine back on. If the error persists, notify
service department
Switch the machine off and on again.
If the error persists, notify service department
Allow the machine to cool down
Switch the machine on and off again.
If the error persists, notify service department
Switch off the machine, place the electrode
holder in an insulated position and switch the
machine back on. If the error persists, notify
service department
Switch the machine on and off again.
If the error persists, notify service department
Allow the machine to cool down
Check wire feed unit,
switch the machine off and on again, inform the
service department if the fault persists.
Switch off the machine and check the mains
voltage
Switch off machine and check welding current
leads for correct installation, e.g., put down
electrode holder in an electrically insulated
manner, disconnect degausser current lead.
