Machine description – quick overview
4
4.1
Front view
Item Symbol
1
2
3
4
5
6
7
099-002057-EW501
04.03.2019
Machine description – quick overview
Description
0
Carrying strap > see 5.1.4 chapter
Machine control > see 4.3 chapter
Connection socket, "-" welding current
•
TIG: Welding current lead connection for TIG welding torch
•
MMA: Electrode holder or workpiece lead connection
Connection socket, "+" welding current
•
MMA: Electrode holder or workpiece lead connection
•
TIG: Connection for workpiece lead
Connection socket, 19-pole
Remote control connection
Cooling air outlet
Machine feet
Figure 4-1
Front view
15
