Pyronix EURO 46 APP Programming Reference Manual page 41

KEYS LOCKED OUT
Authorisation
Required
9.2.3 Detection Faults
Fault
CASE TAMPER
Code Guessing
9.2.4 Power Supply Problems
Fault
BATTERY FAULT
xxx
BAT LOAD FAIL
BAT CRITICAL
MAINS FAIL xxx
LOW VOLTS xxx
9.2.5 Engineer Indications
Fault
Engineer Access
Denied
Check Failed Input
xxx
Error input Areas
not accessible
Error some Areas
cannot be unset
9.2.6 Wireless Faults (If Wireless ZEM installed)
Fault
U-01 (xx)
WLs LOW BATT
I-01 (xx)
WLs LOW BATT
a) More than one device is
connected at the same address.
b) Too many incorrect key presses
have been entered to create a 'Code
Guessing' condition.
The master manager will need to
give the Engineer access
Description
Case tamper switch open
Up to 13 invalid key presses have
been entered or three invalid tags
have been presented.
Description
Battery not present or Battery volts
low
Battery Load Test has failed
Battery being disconnected
Mains supply failed
Power supply volts low
Description
Access to Engineer menu NOT
possible, as system is not fully
unset.
Input in fault on attempting to exit
Engineer mode.
An input has been programmed to
an area for which no setting point is
valid to unset.
Setting points have been
programmed so it is possible to set
an area, but not unset it.
Description
Low battery on wireless keyfob
(user) number 'xx'
Low battery on wireless input
number 'xx'
a) Ensure correct addressing so that there
are no overlaps. Next, power the system
down and back up again to correctly
reinitialise.
b) Wait 90 seconds for the keypad to be re-
introduced onto the system.
The option 'Allow Engineer Menu' will need to
be enabled by the master manager
Solution
Ensure the switch is closed
Press the 'NO' key to clear.
Solution
Note: This indication should be expected
during recharge after a mains failure.
Only displays if the option is selected. If the
battery is uncharged or the capacity is below
specification, then it may need replacing.
Protects the battery from deep discharge
damage during an extended mains failure.
Note: The system is about to be powered
down!
The system detects that the mains frequency
is out of specification, as well as voltage.
Note: 'AC FAIL' timer operative.
Battery volts below normal 'battery fault'
level during a mains failure.
Solution
Ensure that ALL areas are unset, using
suitable user codes/tags at the appropriate
keypads/readers.
Applies to 24-hour tamper, or other input
types that would generate an alarm condition
if the system were returned to unset mode.
This also applies to tamper faults on other
input types. Check for the fault on input, or
omit it in programming.
It would be impossible to fully unset the
system after a tamper alarm on that input.
Programming must be adjusted before
exiting Engineer mode.
Programming must be adjusted before
exiting Engineer mode.
Solution
Replace the battery on the keyfob
mentioned.
Replace the battery on the input device
mentioned.
Page: 41
