Pyronix EURO 46 APP Programming Reference Manual page 10

22 Input Line Fail
Keyswitch
23
*
Pulsed
29 Interior
32 Flood
39 CCTV
40 Perimeter
41 Keybox
42 Medical
43 Final Exit 2
Input Areas: Enter the areas (0,1,A,B,C,D) for input to operate in.
Input Areas (Any or All)
In some installations a 'common' area may be required. A common area is an area that only sets when
other specific areas become set. Example: An entry and exit reception area in a building may only
need to be set if both the offices and warehouse are set. If the office in Area A is set, but the
warehouse in Area B is still occupied, then the reception would still need to be inactive so people would
be able to leave the premises via the entry / exit reception route. One input can be allocated to one or
more areas. In this example the inputs located in the reception area will be programmed so that the
reception inputs will be in Area A and Area B, so these inputs must have the Input Areas set as 'ALL'
programmed.
Area A: Office - Inputs = 3, 4, 5
Area B: Warehouse - Inputs = 6, 7, 8
Reception inputs – 1 and 2 are programmed into both Areas A and B, with both inputs configured as
'ALL'. The Reception Area inputs will now only become active if both Area A and Area B are both set.
5.4.2 Input Attributes?
Attribute Operation for both wired and wireless inputs
Chime When enabled the system loudspeaker(s) will 'chime' when an input is triggered while
the alarm panel is unset. Chime can be set to 'single' (sounding once) or 'follow'
(sounding while the door is left open). NOTE: The chime can be turned on or off in
unset mode by pressing [c] when all Entry Delay inputs are closed.
Omittable Enables the input to be manually omitted (disabled) from the setting procedure. To
omit inputs, there is a function in the Master Manager menu called 'OMIT INPUTS'.
Double If enabled, if this input is triggered twice within the pre-programmed time window or
if the input remains active for that period, an alarm will be generated. The double
Knock
knock option does not work on 'Follow' input type.
Dual Trip The control panel will only generate an alarm if this input, and another
like-programmed input (with adjacent number), are in alarm condition at the same
time. Either input in alarm condition will prevent the system from setting.
This input type is designed specifically for use with systems installed using BS8243
option 6.4.5.This input type is always used in conjunction with an Entry/Exit input.
The Entry/Exit input is a door contact on the initial entry door, and the Entry Shock
input is a non-latching shock sensor fitted to the door frame in the vicinity of the
lock. If the initial entry door is subjected to gross attack and forced open, then at
the expiry of entry time only one further intruder input need to be activated to
signal a sequentially confirmed alarm – the Entry Shock input counts as the first
to alarm. The Entry/Exit door contact must be opened with 10 seconds of the shock
detector triggering for the Entry Shock response to apply. Triggering the Entry
Shock input in isolation will NOT generate an alarm of any kind.
Active when fail. Will give a line fault alarm, and will signal telecom line fault
signal on expiry of line fault timer. Works in conjunction with CCTV input.
Accepts input from keyswitch (or equivalent) to Set/Unset the Set modes assigned
to it. Requires momentary action switch to toggle set/unset state.
Active when set. Audible response: full communicator – intruder and
unconfirmed signals. Will send interior event when using Contact ID /Contact ID IP.
Active when set or unset. This input type will work as a 24hr input, any inputs
that are programmed for Flood will activate the external siren. Full communicator:
intruder and unconfirmed signals, flood event sent via Contact ID / Contact ID IP.
Active at all times. No audible or communicator response
If the input line fail is active, the system will signal CID/SIA events for
perimeter alarm and the CCTV input will open.
Active when set. Audible response: full communicator – intruder and unconfirmed
signals. Will send perimeter event when using Contact ID /Contact ID IP.
Export: Similar to switcher input, but sends a Contact ID event of
'keybox'
Export: Sends a medical Contact ID event when activated.
This is useful if you would like to set different times for the front door and the back
door of a house for example. See 'Final exit' listed above - for more details
Page: 10
