Boogie Drive
2 ADJUSTMENTS
2.1 ASSEMBLY GROUP WHEELS

2.1.1 Wheel position

The chart below shows which distances and dimensions
with which body height and with which driving wheel are
possible.
The chart on the next page (page 9) explains, where
the quick release axle fittings and the axle plate need to
be mounted when the wheel size and/or the camber is
changed.
(1) With the horizontal change of the wheel position along
the hole rows 1, 2 or 3 you change the gripping distance
and the centre of gravity.
ATTENTION
A verticle adjustment of the wheel position is only
possible when the wheel size is changes at the same
time.
(2) To change the wheel position remove the driving wheels
and secure the mobile standing device from rolling away with
the wheel locks of the back casters:
• Remove the quick release axle fitting (A) on both
sides incl. the drum brake counterholder (B),
• place the fittings (A) in the desired new position
(see chart p.9) and retighten it.
• Proceed with the counterholder (B) in the same
manner.
• Make sure that the fittings (A) are mounted symet-
rical on both sides.
Frame size
Body height
A Wheel size
Recomended at
elbow height
B Foot plate to top
handrim
C Upper 0°
distance
3°
between
6°
the wheels
9°
with
camber:
12°
Frame size
Body height
A Wheel size
Recomended at
elbow height
B Foot plate to top
handrim
C Upper 0°
distance
3°
between the
6°
wheels with
9°
camber:
12°
8
Size 1
80-110 cm
24"x1" 26"x1"
ø58 cm ø63 cm
47 cm 52 cm
39-47 cm 44-52 cm
not possible not possible
44 cm 44 cm
42 cm 41 cm
40 cm 38 cm
37 cm 35 cm
Size 3
120-150 cm
32"x1"
ø80 cm
71 cm
61-69 cm
58 cm
55 cm
51 cm
48 cm
not possible
(1)
1
2
3
(2)
28"x1" 28"x1"
ø68 cm ø68 cm
57 cm 57 cm
49-57 cm 49-57 cm
not possible not possible
43 cm 55 cm
40 cm 52 cm
37 cm 49 cm
33 cm 46 cm
36"x1"
ø90 cm
81 cm
71-79 cm
58 cm
54 cm
49 cm
45 cm
not possible
(A) (B)
Size 2
100-130 cm
30"x1" 32"x1"
ø75 cm ø80 cm
64 cm 69 cm
56-64 cm 61-69 cm
not possible not possible
54 cm 54 cm
50 cm 50 cm
47 cm 46 cm
44 cm 42 cm
