TFT Flat-Panel Connector (FPNL2)

The 31-pin FPNL2 connects to a TFT flat-panel display. The flat-panel type and
panel logic voltage are jumper selectable (refer to the Jumper Settings section earlier
in this chapter).

Backlight Inverter Connector (DCINV1)

This eight-pin connector provides power for the backlight inverter.
Do not use excessive force or pressure to engage the connectors.
Pin Signal Pin
1 GND 17
2 SHFCLK 18
3 LP 19
4 FLM 20
5 GND 21
6 LP(18) 22
7 LP(19) 23
8 LP(20) 24
9 LP(21) 25
10 LP(22) 26
11 LP(23) 27
12 GND 28
13 LP(10) 29
14 LP(11) 30
15 LP(12) 31
16 LP(13)
Pin Signal
1 +12V (switched)
2 +12V (switched)
3 Undefined Voltage
4 Undefined Voltage
5 Undefined Voltage
6 Undefined Voltage
7 GND
8 GND
Caution
Signal
LP(14)
LP(15)
GND
LP(2)
LP(3)
LP(4)
LP(5)
LP(6)
LP(7)
GND
M
VCCSW
VCCSW
R/L
U/D
