CHIP4e+ Manual

AC Input Connector (ACIN1)

AC Supply Connector (ACOUT1)

This three-pin connector connects the power supply to the CPU.

H8 Boot Program (PROGH3)

This eight-pin connector programs the H8 for the first time.

Ethernet Connector (ETHER1)

This eight-pin connector provides 10BASE-T and 100BASE-TX Ethernet
connections.

PC/104 Connector (P7 and P8)

This 32-pin connector allows you to connect PC/104 cards.
The PC/104 connector does not support cards that need -5V.
Pin
30
Pin AC Signal
1 L
2 N
3 AC_GND
Pin AC Signal
1 L
2 NC
3 N
Pin Signal
1 GND
2 TXD1
3 RXD1
4 RES*
5 +5V
6 +12V
7 MD1
8 GND
Pin Signal
1 TX+
2 TX-
3 RX+
4 Short to pin 5 75ohm to TERMPLANE
5 Short to pin 4 75ohm to TERMPLANE
6 RX-
7 Short to pin 8 75ohm to TERMPLANE
8 Short to pin 7 75ohm to TERMPLANE
Note
Row A Row B
DC Signal
+DC
-DC
GND
DC Signal
+DC
NC
-DC
Row C Row D
