Appendix B – Video Modes
The Chips & Technologies VGA BIOS supports many standard, VESA, and
extended modes. The following tables list the standard and extended video modes,
and whether or not they are supported by CRT, TFT active color, and STN passive
color displays.

Standard Modes

IBM Mode VESA Mode
00 Not Supported
01 Not Supported
02 Not Supported
03 Not Supported
04 Not Supported
05 Not Supported
06 Not Supported
07 Not Supported
0D Not Supported
0E Not Supported
0F Not Supported
10 Not Supported
11,20 Not Supported
12 Not Supported
13 Not Supported
# of Colors Pixels
16/256 320x200
16/256 320x350
16/256 640x200
16/256 640x200
4/256 320x200
4/256 320x200
2/256 640x200
mono 720x350
16/256 320x200
16/256 640x200
mono 640x350
16/256 640x350
2/256 640x480
16/256 640x480
256/256 320x200
Display CRT
Mode
text Supported
text Supported
text Supported
text Supported
graphics Supported
graphics Supported
graphics Supported
text Supported
graphics Supported
graphics Supported
graphics Supported
graphics Supported
graphics Supported
graphics Supported
graphics Supported
TFT STN
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported Supported
47
