Touch Connector (TCH1)

This five-pin connector interfaces to the touch screen.

STN Flat-Panel Connector (FPNL1)

The 34-pin FPNL1 connects to a STN flat-panel display. The flat-panel type and
panel logic voltage are jumper selectable (refer to the Jumper Settings section earlier
in this chapter).
28
Pin Signal
1 UR
2 LR
3 SENSE
4 LL
5 UL
Pin Signal
1 LP(15)
2 LP(14)
3 LP(13)
4 LP(12)
5 LP(7)
6 LP(6)
7 LP(5)
8 LP(4)
9 VCCSW
10 GND
11 NC
12 SW_VEE
13 SW_VEE
14 VCONT
15 FLM
16 NC
17 ENAVEE(DISP)
Pin Signal
18 LP
19 GND
20 SHFCLK
21 GND
22 LP(11)
23 LP(10)
24 LP(9)
25 LP(8)
26 LP(3)
27 LP(2)
28 LP(1)
29 LP(0)
30 NC
31 NC
32 +5V
33 SWVCC
34 WIPER
