Keypad Connector (KEYPAD1)

This 20-pin connector provides the keypad interface.
32
Pin Signal Pin
1 GND 11
2 KSO(9) 12
3 KSO(10) 13
4 KSI(0) 14
5 KSI(1) 15
6 KSI(2) 16
7 KSI(3) 17
8 KSI(4) 18
9 KSI(5) 19
10 KSI(6) 20
Signal
KSI(7)
KSO(0)
KSO(1)
KSO(2)
KSO(3)
KSO(4)
KSO(5)
KSO(6)
KSO(7)
KSO(8)
