0 - -
1 IOCHCK* GND
2 SD7 RESETDRV
3 SD6 +5V
4 SD5 IRQ9
5 SD4 NC
6 SD3 DRQ2
7 SD2 -12V
8 SD1 0WS*
9 SD0 +12V
10 IOCHRDY NC
11 AEN SMEMW*
12 SA19 SMEMR*
13 SA18 IOW*
14 SA17 IOR*
15 SA16 DACK3*
16 SA15 DRQ3
17 SA14 DACK1*
18 SA13 DRQ1
19 SA12 REF*
20 SA11 SYSCLK
21 SA10 IRQ7
22 SA9 IRQ6
23 SA8 IRQ5
24 SA7 IRQ4
25 SA6 IRQ3
26 SA5 DACK2*
27 SA4 TC
28 SA3 ALE
29 SA2 +5V
30 SA1 OSC
31 SA0 GND
32 GND GND
GND GND
SBHE* MEMCS16*
LA23 IOCS16*
LA22 IRQ10
LA21 IRQ11
LA20 IRQ12
LA19 IRQ15
LA18 IRQ14
LA17 DACK0*
MEMR* DRQ0
MEMW* DACK5*
SD8 DRQ5
SD9 DACK6*
SD10 DRQ6
SD11 DACK7*
SD12 DRQ7
SD13 +5V
SD14 MASTER*
SD15 GND
NC GND
